PE / PPR Pipe Extrusion Production Line

PE32-2000

Quantity:

Contact Now

add to cart

Features:

PO series extrusion equipment was adopted latest Europe advanced technology by “WPLAS”, through digestion and absorption, Successfully developed new type pipe extrusion line. Suitable for PE, PPR, PP, PB, PE-RT, PEX, PA, PVDF etc. The complete set of extrusion equipment is equipped with super length-diameter ratio extruder, frequency conversion vacuum sizing, Dust-free cutting, not only high efficiency, high speed and beautiful appearance, high degree of automation, stable and reliable production. It’s welcomed by clients for its “Europen performance but Chinese price”. It can also produce multi-layer composite pipe, agriculture irrigation pipe and cable protection pipe, etc. It is the best choice replacing imported extrusion equipments.

Main parameters:

Model	Working range (mm)	Capacity (kg/h)	Haul off speed (m/min)	Central height (mm)	Dimension (m)	Control system
PE32-2	2×Ф12-Ф32	300～450	2×1-35	1000-1050	46×3.8×1.8	Computer control
PE63-2	2×Ф16-Ф63	350～500	2×1-25	1000-1050	47×3.8×1.9
PE63	Ф16-Ф63	300～450	1-35	1000-1050	49×3.1×1.9
PE110	Ф20-Ф110	300～450	0.6-20	1000-1050	46×3.2×2.0
PE160	Ф40-Ф160	320～500	0.6-18	1000-1050	50×3.2×2.0
PE250	Ф50-Ф250	500～650	0.5-10	1000-1050	52×3.3×2.2
PE315	Ф63-Ф315	550～700	0.3-8	1000-1050	53×3.4×2.3
PE450	Ф110-Ф450	800～900	0.2-4.5	1100-1150	56×3.5×2.7
PE630	Ф250-Ф630	850～1000	0.1-2.6	1100-1150	62×3.6×2.8
PE800	Ф400-Ф800	900～1100	0.1-1.5	1200-1250	69×3.6×3.0
PE1000	Ф500-Ф1000	1000～1300	0.08-1.0	1400-1450	72×3.6×3.0
PE1200	Ф630-Ф1200	1200～1400	0.07-0.8	1600-1650	75×3.8×3.0
PE1600	Ф710-Ф1600	1400～1650	0.05-0.6	1800-1850	76×4.0×3.2
PE2000	Ф1400-Ф2000	1600～1800	0.02-0.3	2200-2250	82×4.5×4.8
